KYN61 40.5 armored mobile AC metal enclosed switchgear
Product Overview
The KYN61 - 40.5(Z) Armored withdrawable AC metal - enclosed switchgear is a high - quality electrical product designed for modern power distribution systems. This KYN61 - 40.5(Z) Armored withdrawable AC metal - enclosed switchgear combines advanced technology and reliable performance to meet the diverse requirements of different power applications.
The “armored” feature of this switchgear provides a high level of protection. It safeguards the internal components from external interference and potential mechanical damage, ensuring the long - term stable operation of the electrical system. The armored withdrawable AC metal - enclosed switchgear design allows for easy maintenance and replacement of parts. When maintenance is required, the withdrawable part can be conveniently removed, minimizing the downtime of the power system and reducing the impact on normal production and life.
As an AC metal - enclosed switchgear, it effectively isolates the electrical conductors and components from the external environment. This not only enhances the safety of the operation but also helps to prevent electrical leakage and short - circuit faults. The metal enclosure also offers excellent electromagnetic shielding performance, reducing electromagnetic interference to surrounding equipment.
The KYN61 - 40.5(Z) model is specifically designed for a rated voltage of 40.5 kV, making it suitable for medium - voltage power distribution networks. It can handle relatively large power loads and is widely used in industries such as power plants, substations, and large - scale industrial and commercial facilities.
In summary, the KYN61 - 40.5(Z) Armored withdrawable AC metal - enclosed switchgear is a highly reliable, efficient, and safe electrical product. Whether it is for new power system construction or the upgrading of existing systems, this switchgear is an excellent choice that can bring stable power supply and strong protection to your power system.
KYN61-40.5(Z) armored removable AC metal-enclosed switchgear is suitable for power systems with a frequency of 50Hz, a rated voltage of 40.5kV and a rated current of up to 3150A. It has the functions of control, protection and monitoring of the circuit. Can be widely used in general power systems.
KYN61-40.5(Z) type armored removable AC metal-enclosed switchgear (hereinafter referred to as “switchgear”) is suitable for three-phase AC 5 0 Hz power systems, used in power plants, substations and industrial and mining enterprises The power distribution room is used to receive and distribute electric energy, and to control, protect and monitor the circuit.
This product meets the standards: GB3906 “3~35kV AC metal-enclosed switchgear”, GB/T11022 “High-voltage switchgear and control equipment standard common technical requirements”, IEC60298 “rated voltage above 1kV and below 50kV AC metal-enclosed switchgear and control equipment “.
-
Integrated, miniaturized, and modularized product development with wide applicability.
-
“Five-defense” locking device design, safe and reliable.
-
The cabinet has strong anti-corrosion and anti-oxidation properties.
-
Adopt balanced electric field measures, and the busbar is insulated with heat-shrinkable material, which has high insulation performance.
-
The protection level can reach IP4X.
Technical Parameters:
Ambient air temperature: upper limit temperature +40°C. The lower limit temperature is -15°C.
Relative humidity: daily average relative humidity: ≤95%, daily average water vapor pressure not exceeding 2.2KPa; monthly average relative humidity: ≤90%, monthly average water vapor pressure not exceeding 1.8KPa;
Altitude: below 1000m.
Earthquake intensity: no more than 8°C.
The surrounding air should not be significantly polluted by corrosive or combustible gases, water vapor, etc.
No place with severe vibration.
When it is used under the normal conditions specified in GB3906, it shall be negotiated by the user and the manufacturer
