KYN28 12 armored removable AC metal enclosed switchgear
Product Overview
The KYN28-12(Z) AC Metal-clad Switchgear is an advanced and reliable electrical equipment designed for power distribution systems. This switchgear offers high - performance and stable operation in various industrial and commercial applications.
KYN28-12(Z) AC Metal-clad Switchgear is built with a robust metal - clad structure, which provides excellent protection for internal components from external environmental factors. It effectively isolates electrical parts, reducing the risk of electrical faults and ensuring the safety of operators and equipment.
One of the key features of the KYN28-12(Z) AC Metal - clad Switchgear is its high - quality insulation materials. These materials can withstand high - voltage conditions, minimizing the possibility of electrical breakdown and enhancing the overall reliability of the switchgear.
In addition, this switchgear is equipped with advanced control and protection systems. The intelligent control system allows for precise monitoring and control of electrical parameters, while the protection system can quickly detect and respond to faults such as over - current, over - voltage, and short - circuit, effectively protecting the power system and connected equipment.
The KYN28-12(Z) AC Metal - clad Switchgear also features easy installation and maintenance. Its modular design enables convenient assembly and disassembly, reducing installation time and cost. At the same time, the accessible structure makes maintenance work more efficient and less time - consuming.
Whether it’s a small - scale industrial facility or a large - scale commercial building, the KYN28 - 12(Z) AC Metal - clad Switchgear is an ideal choice for ensuring a stable and safe power supply. With its outstanding performance and reliable quality, it can meet the diverse needs of modern power distribution systems.
KYN28-12 type (GZS1) armored removable AC metal-enclosed switchgear (hereinafter referred to as switchgear) is a three-phase AC 50Hz indoor complete power distribution device, used to receive and non-distribute 3-12KV network power and The circuit implements control protection and supervision. Various types of microcomputer integrated relay protection devices are installed on the panel of the relay chamber of this product, and can realize the intelligent control of the system. It has the functions of remote control, telemetry, remote signaling and remote adjustment, and is controlled by CAN bus with communication interface. The on-site network also has the functions of preventing misoperation of circuit breakers, preventing pulling back of the handcart with load, preventing grounding switch from being closed with a point, preventing the grounding switch from transmitting power at the grounding position and preventing accidental entry into the charged interval, namely the “five prevention” functions for short.
The cabinet can be equipped with VSI (ZN63), ZN12V vacuum circuit breaker, imported VD4 vacuum circuit breaker and VC series vacuum contactor.
The shell and partition of the switchgear are made of high-quality imported aluminum-zinc-coated steel plates processed by CNC machine tools and then bolted, so the assembled switchgear can maintain the uniformity in size. It has strong anti-corrosion and anti-oxidation effects, and has higher mechanical strength than the same steel plate. The switch cabinet is divided into handcart room (circuit breaker compartment), busbar room, cable room, relay instrument room (low voltage room) by partitions. Each unit case is independently grounded.
The cabinet shell and partitions of the switchgear are made of aluminum-zinc-coated steel plates or steel plates processed by CNC machine tools and then bolted after bending, so the assembled switchgear can maintain the uniformity in size. Aluminum-zinc clad steel plate has strong anti-corrosion and anti-oxidation effects, and has higher mechanical strength than the same steel plate. The switchgear is divided into handcart room, busbar room, cable room and relay instrument room by the partition, and the shell of each unit has independent grounding. The parts of the switchgear are all electrostatically sprayed to make the surface have the advantages of anti-collision, corrosion resistance, beautiful appearance (the color can be customized by the user), etc.
Normal use conditions:
◆Ambient air temperature: upper limit temperature +40℃. The lower limit temperature is -15°C.
◆Relative humidity: daily average relative humidity: ≤95%; daily average water vapor pressure not exceeding 2.2KPa;
Monthly average relative humidity: ≤90%; monthly average water vapor pressure does not exceed 1.8KPa;
◆Altitude: below 1000m.
◆Earthquake intensity: no more than 8℃.
◆The surrounding air should be free from obvious pollution such as corrosive or combustible gas and water vapor.
◆No place with severe vibration.
◆When it is used under the normal conditions specified in GB3906, the user shall negotiate with the company.
